Cladding Boards



Engineered Stone Board
Thickness: 12 mm – 20 mm
Max panel size (custom): up to 2.5 × 1.25 m
Design density: ≈ 1,800 – 2,200 kg/m³

Key metric Value
Nominal weight 12 mm → ~24 kg/m²
20 mm → ~40 kg/m²
Flexural strength 8–18 MPa
Water resistance Very Good
Fire resistance Non-combustible
Thermal conductivity 0.7–1.6 W/m·K
Typical tolerance ±0.5–1.0 mm
Machinability Hard — diamond tooling

Textures

  • Smooth
  • Brushed
  • Sandblasted
  • Terrazzo
  • Aggregate
  • Custom

Practical uses

  • External cladding & rainscreen facades (when detailed)
  • Heavy-duty interior & exterior flooring (commercial & residential)
  • Stair treads, landings & thresholds
  • High-end countertops and work surfaces
  • Wet areas (pools, showers) with appropriate sealing
  • Sophisticated decorative panels and inlaid murals

Glassfibre Reinforced Concrete Board
Thickness: 10 mm – 30 mm
Max panel size (custom): up to 3.0 × 1.5 m
Design density: ≈ 1,600 kg/m³ – 1,800 kg/m³

Key metric Value
Nominal weight 10 mm → ~18 kg/m²
30 mm → ~54 kg/m²
Flexural strength 8–25 MPa
Water resistance Very Good
Fire resistance Non-combustible
Thermal conductivity 0.7–1.0 W/m·K
Typical tolerance ±0.5 mm(thin) → ±1.0 mm (thick)
Machinability Moderate — diamond tooling

Textures

  • Plain
  • Colored
  • Custom

Practical uses

  • Architectural façade cladding & rainscreens
  • Curved panels, cornices, fins and decorative mouldings
  • Perforated sunscreens and acoustic screens
  • Balconies/terraces & lightweight structural panels
  • Bespoke architectural commissions
